DX Music League — A Tour of the Source Code

DX Music League is a self-hosted clone of Music League: players join a league, each round has a theme, everyone submits a song, players vote by spreading a pool of points across the submissions, and scores accumulate on a leaderboard across rounds. It's live in beta with real users, running entirely on AWS serverless infrastructure — and the whole thing also runs 100% offline on your laptop with zero configuration.

This post walks through every piece of the codebase: how the frontend, backend, and infrastructure fit together, and the handful of architectural decisions that everything else hangs off.

The one big idea: ports and seams

Almost everything interesting about this codebase follows from a single pattern, applied three times on the frontend and once on the backend: define a small interface (a "port"), write a mock implementation and a real implementation, and select between them with environment variables.

The consequence: npm run dev with no .env gives you a fully working app — you sign in as a seeded user ("Curator Max"), browse seeded leagues, submit songs from a demo catalog, vote, and reveal results — without touching AWS. Set three env vars and the exact same code talks to Cognito, API Gateway, and DynamoDB.

Repository layout

dxmusicleague/
├── src/                      # Frontend (Vite + React 19 + TS)
│   ├── main.tsx, App.tsx     # Bootstrap + routes + auth guards
│   ├── auth/                 # AuthBackend port, Cognito + mock impls
│   ├── data/                 # DataClient port, API + mock impls
│   ├── music/                # MusicProvider port + provider registry
│   ├── domain/types.ts       # Core model (League, Round, Ballot, ...)
│   ├── pages/                # One folder-flat file per screen
│   ├── components/           # AppLayout, Tutorial, Avatar, TrackArt
│   ├── lib/                  # useAsync, time helpers
│   └── styles/global.css     # Design tokens ("Sonic Syndicate" theme)
├── backend/
│   ├── infra/                # CDK app + stack
│   └── src/
│       ├── http/             # routes.ts + lambda.ts + local-server.ts
│       ├── handlers/         # Service layer (leagues, rounds, voting, ...)
│       ├── domain/           # types, errors, rules.ts (the referee)
│       └── data/             # Repository port, memory + dynamo impls
├── docs/                     # Design docs (data model, YT Music PoC)
├── poc/ytmusic_search.mjs    # Standalone YouTube Music search spike
├── vite-plugin-ytmusic.ts    # Dev-only YT Music search proxy
└── scripts/deploy-frontend.sh

Frontend

Bootstrap and routing

src/main.tsx imports polyfills.ts first — it shims a Node-style Buffer global that the Cognito SDK expects (without it, the app blanks with "Buffer is not defined"). vite.config.ts handles the companion problem with define: { global: 'globalThis' }.

src/App.tsx sets up BrowserRouter → AuthProvider → Routes with two guards:

• RequireAuth — redirects to /signin, carrying state={{ from: location.pathname + location.search }} so an invite link (/leagues/join?code=DXL-XXXXXX) survives the sign-in round trip.
• RedirectIfAuthed — keeps signed-in users off the auth screens.

All authenticated routes nest inside AppLayout (sidebar + outlet). The route table covers: dashboard (/), leagues list/create/join, per-league hub (/leagues/:leagueId) plus submit, vote, reveal, settings, and preview sub-pages, cross-league /rounds, /leaderboard, /profile, and /help.

The auth seam (src/auth/)

The port:

export interface AuthBackend {
  readonly requiresConfirmation: boolean;
  currentUser(): Promise<AuthUser | null>;
  idToken(): Promise<string | null>;
  signUp(input: SignUpInput): Promise<SignUpResult>;
  confirmSignUp(email: string, code: string): Promise<void>;
  resendCode(email: string): Promise<void>;
  forgotPassword(email: string): Promise<void>;
  confirmForgotPassword(email: string, code: string, newPassword: string): Promise<void>;
  signIn(email: string, password: string): Promise<AuthUser>;
  signOut(): Promise<void>;
  updateDisplayName(displayName: string): Promise<AuthUser>;
}

CognitoAuth wraps amazon-cognito-identity-js — pure browser-side SRP, no Amplify. It normalizes SDK errors into an AuthError carrying a .code that pages branch on; the important one is UserNotConfirmedException, which the sign-in page catches and turns into a redirect to /confirm with a freshly re-sent code, instead of dead-ending the user.

MockAuth persists a fake session in localStorage, signs you in as seed user u-me ("Curator Max" — the same identity the mock data store treats as "me"), and has one clever test affordance: any email containing the string "unconfirmed" simulates Cognito's needs-verification flow, so the whole confirm-email UX is exercisable offline.

AuthContext.tsx wraps whichever backend config.ts selected in a React context, restoring the session on mount so there's no signed-out flash.

The data seam (src/data/)

DataClient is the frontend's entire view of the backend — about 25 methods covering league CRUD/join/leave/kick, public discovery and previews, rounds, submissions, ballots, and results. Pages import a single data singleton from src/data/index.ts:

export const isApiMode = Boolean(import.meta.env.VITE_API_URL);
export const data: DataClient = isApiMode ? new ApiClient() : new MockClient();

ApiClient is thin: fetch against VITE_API_URL with Authorization: Bearer ${await auth.idToken()} on every request, JSON parsing, and an ApiRequestError(status, message) on failure. MockClient wraps mock.ts, an in-memory store seeded with 7 leagues and 10 rounds spanning every status — including two submissions deliberately tied on points to exercise the tie-break rule in the UI.

The music seam (src/music/)

The port every screen uses to touch a music catalog:

export interface MusicProvider {
  readonly info: MusicProviderInfo;
  searchTracks(query: string, opts?: SearchOptions): Promise<Track[]>;
  getTrack(providerTrackId: string): Promise<Track | null>;
  createPlaylist(name: string, tracks: Track[], description?: string): Promise<Playlist>;
}

Nothing in the UI or domain references Spotify directly. A league stores a musicProvider id; screens call getProvider(league.musicProvider) and render provider.info.name. Tracks are normalized into a provider-agnostic Track shape with id = "${provider}:${providerTrackId}".

Three registered providers:

• MockMusicProvider — a 10-track in-memory demo catalog with client-side substring search.
• SpotifyMusicProvider — never talks to Spotify from the browser. Everything goes through the backend proxy (GET /spotify/search, etc.) with the Cognito bearer token attached; players never authenticate with Spotify at all.
• YouTubeMusicProvider — same proxy pattern, targeting /youtube-music/* endpoints. In dev, a bundled Vite plugin serves those endpoints locally (more in the last section).

One deliberate gate: the create-league picker calls listProviderOptions(), which is hardcoded to return only Spotify for the beta. Existing leagues on other providers keep working through the registry; new leagues can't pick them until the option is added back — a one-line change.

Pages, briefly

• Dashboard — your leagues as cards (status pill, avatar stack, completion bar) plus a "Trending Leagues" strip of open public leagues.
• Leagues — Your Leagues, Discover (open public leagues you can claim a spot in), and Leagues in Progress (spectate anything running).
• Create League — name, music service, rounds (1–20), manual vs. timed progression (timed currently behind a TIMED_ROUNDS_ENABLED = false beta gate), visibility, and player cap for public leagues.
• Join League — invite-code entry; ?code= in the URL prefills and auto-joins once.
• Round Overview — the league hub. Owner round controls drive the lifecycle (create round → open submissions → reveal songs → open voting → reveal results), plus the invite panel, a round stepper linking finished rounds to their reveals, participation panels (who's submitted/voted — names only, never picks), and the standings sidebar.
• Submit Song — debounced provider search, track card with preview playback, optional comment; handles the 1–5 songs-per-player allowance with remove buttons and a locked form when slots are full.
• Vote — spread the point pool across anonymized submissions with steppers clamped to both the remaining pool and the per-song cap; optional anti-votes (💔); per-song comments. Pre-fills from your cast ballot so editing never wipes what you wrote.
• Reveal — winner card with the +for/−against breakdown, the submitter's note, voter comments, the full ranked list, the round playlist link, and the leaderboard. ?round= lets you revisit any past round.
• Leaderboard / Profile / Help — per-league standings tabs; editable display name plus cross-league stats; a wiki-style help center with scroll-spy TOC and a replayable six-step guided tour (auto-shown on first sign-in, tracked per user in localStorage).

Styling and mobile

No CSS framework. Each page has a co-located .css file, and styles/global.css defines the design tokens — a dark purple "Sonic Syndicate" theme with gradient accents. At ≤820px the sidebar disappears in favor of a fixed bottom tab bar (--mobilenav-h includes env(safe-area-inset-bottom) for the iPhone home indicator), and small inputs bump to 16px to defeat iOS Safari's focus auto-zoom.

Backend

The backend is a REST API built on AWS CDK, but designed so the exact same handler code runs locally against an in-memory store. It's Node ESM TypeScript run with --experimental-strip-types — no build step for dev or tests.

  local dev  ───────▶  routes.ts (shared)  ◀─────── API Gateway + Lambda
  http/local-server.ts   handlers/*.ts               http/lambda.ts
  (Node http,            domain/rules.ts             (Cognito-authorized)
   x-dev-user auth)             │ Repository port (data/repository.ts)
                     ┌──────────┴──────────┐
            MemoryRepository          DynamoRepository

The HTTP layer (src/http/)

routes.ts exports a flat, transport-agnostic route table:

export interface Route {
  method: string;
  pattern: string;                 // ":name" segments, e.g. "/leagues/:leagueId"
  handler: (req: RouteRequest) => Promise<unknown>;
}
export interface RouteRequest {
  caller: string;                  // Cognito sub, or dev stub locally
  params: Record<string, string>;
  query: Record<string, string>;
  body: unknown;
}

matchRoute does simple segment matching (literals registered before :param routes so /leagues/browse wins over /leagues/:leagueId). Two adapters consume the same table:

• lambda.ts (production) — reads the caller from event.requestContext.authorizer.claims.sub (API Gateway's Cognito authorizer has already validated the JWT), maps thrown ApiErrors to status codes, adds CORS headers.
• local-server.ts (dev) — a plain Node http server on 127.0.0.1:8787 over MemoryRepository, with the caller stubbed from an x-dev-user header (default u-me).

Adding an endpoint means adding one table entry; both transports pick it up.

The known gotcha: route entries do not pass req.body through to handlers. Each one rebuilds the handler input from an explicit field list:

const body = asRecord(req.body);
return leagues.createLeague(deps, req.caller, {
  name: asString(body.name),
  musicProvider: body.musicProvider as never,
  visibility: body.visibility as never,
  maxMembers: typeof body.maxMembers === "number" ? body.maxMembers : undefined,
  // ...
});

Any field not named here is silently dropped before the handler ever sees it. That's a nice input-sanitization property, but it means adding a request field is a two-place change: the handler's input type and the route entry. Forgetting the route half produced a real bug once (a new settings field that saved as a no-op).

The service layer (src/handlers/)

Every handler has the shape (deps: Deps, caller: string, ...args) => Promise<result> where Deps = { repo: Repository; users: UserDirectory }, and throws typed ApiErrors (400/401/403/404/409) from domain/errors.ts.

• leagues.ts — the biggest one. Create (with validation: round count 1–20, public leagues need a 2–50 player cap, timed leagues need phase lengths), join by invite code, claim a spot in a public league, leave/kick, invite regeneration, settings, cascade delete. League detail hydrates rounds, runs auto-advance before reading standings (so a just-revealed round's points are banked), computes live submission/voting progress panels, and derives an activity feed from submission/ballot timestamps. Privacy rules are explicit and tested: spectators get inviteCode: "", and progress/activity leak identities only — never tracks or vote allocations. League ids and DXL-XXXXXX invite codes come from crypto randomness with an unambiguous alphabet (no I/L/O/0/1) — deliberately not a counter, which would reset on Lambda cold start and collide.

• rounds.ts — owner-only lifecycle. Phase transitions are gated by a fixed map, so no skipping and no going backward:

  ts

  const ALLOWED_NEXT: Record<RoundStatus, RoundStatus[]> = {
    draft: ["submitting"], submitting: ["previewing"], previewing: ["voting"],
    voting: [], revealed: [], complete: [],
  };

  Reveal isn't reachable via a raw PATCH at all — it has its own endpoint with its own rules. Closing submissions triggers best-effort playlist creation (a Spotify hiccup never blocks the round).

• submissions.ts — submit/replace/remove with the songs-per-player allowance. With allowance 1, re-submitting replaces your pick but keeps a stable submission id, so a ballot referencing it can't be pulled out from under a voter. Duplicate rejection: within a round, no two picks may be the same song and no artist may appear twice — checked against everyone's picks. The votable list returns everyone's submissions except your own, stripped to { id, track } — fully anonymous.

• voting.ts / results.ts — cast ballot (delegating all rule enforcement to domain/rules.ts), ballot pre-fill (getMyBallot), owner reveal, and results. finalizeReveal tallies, ranks, and banks each submitter's net points into standings — shared by manual reveal and timed auto-advance so both settle identically.

• progression.ts — timed rounds without a scheduler. autoAdvanceRound runs on reads and after writes, cascading a round through every phase whose deadline has passed or where everyone has finished (everyone submitted / everyone voted). Finishing early re-bases the next deadline from now; a league nobody opened for a week catches up in a single read.

• providers.ts — the Spotify proxy. Search uses the Client Credentials flow with an app-level token cached until ~60s before expiry, limit clamped to 10 (the February 2026 API change). Playlist creation on reveal uses a separate host-account refresh token. Credentials live in Secrets Manager and never leave the Lambda.

The rules engine (src/domain/rules.ts)

Pure functions, no I/O — "the server is the referee":

• validateBallot — every allocation targets a real submission; integer points ≥ 0; per-song max (maxPointsPerSong); no self-votes; and the pool must be spent exactly:

  ts

  if (total !== settings.votePoolSize) {
    throw badRequest(`You must spend exactly ${settings.votePoolSize} points (you spent ${total}).`);
  }

  Anti-votes are optional (0 up to downvotePoolSize, itself capped at 2) and can't target your own song.

• tallyBallots — per-song net points, pointsFor, pointsAgainst, and distinct-voter counts (only positive votes count as a "voter").

• rankSubmissions — the fixed tie-break: points desc → distinct voters desc → title A→Z.

  ts

  b.points - a.points || b.distinctVoters - a.distinctVoters || a.title.localeCompare(b.title)

The data layer (src/data/)

Handlers depend only on the Repository port (~25 methods grouped by entity) plus a separate UserDirectory { getDisplayName } — kept off the repository so the game loop doesn't depend on a user store.

MemoryRepository backs local dev and all tests: plain Maps with structuredClone on every read and write so callers can never mutate the store, seeded with the same fixtures as the frontend mock.

DynamoRepository is a single-table design on a table named MusicLeague:

Details worth noticing:

• Round ids are "<leagueId>~<index4>" — decodable back into the exact PK/SK, so getRound needs no lookup table.
• One ballot per voter is schema-enforced by the BALLOT#<voterId> sort key; re-voting overwrites atomically.
• removeMember deletes only the membership row — the standing row survives, which is what makes leave/rejoin (and kick/re-invite) keep a player's points.
• addStandingPoints uses if_not_exists(points, 0) + delta for create-at-zero semantics.
• Public-league discovery is a filtered Scan, explicitly annotated as fine at current scale with a note to promote it to a GSI if leagues grow.
• Legacy fallbacks everywhere: older single-key submission rows (SUB#<userId>, before the multi-song feature) still read and delete correctly.

Infrastructure (infra/stack.ts)

One CDK stack provisions everything:

• DynamoDB — the single table, on-demand billing, point-in-time recovery, RemovalPolicy.RETAIN.
• Cognito — self-signup user pool, email sign-in with auto-verification, SRP-only web client with preventUserExistenceErrors.
• Secrets Manager — a music-league/spotify secret created empty; real credentials are set out-of-band so they never land in source or the CloudFormation template.
• Lambda — one NodejsFunction (Node 22, 256 MB, 15s) bundling http/lambda.ts with esbuild; the local-server path tree-shakes away.
• API Gateway — a REST API with a Cognito authorizer and a single catch-all proxy resource. The Lambda owns all routing; API Gateway just authenticates and forwards.
• S3 + CloudFront — a private bucket behind Origin Access Control, with the SPA fallback (403/404 → /index.html as 200) so React Router deep links work.

Testing

npm test runs Node's built-in test runner (node --experimental-strip-types --test) — no Jest, no Vitest, zero test dependencies. Around 46 tests across five files cover the rules engine (ballot validation, tie-breaks, anti-vote tallying), league discovery and privacy (spectators never see invite codes; progress panels never leak picks), the submission allowance and duplicate guards, reveal and standings durability, and timed-progression cascades. Everything runs against MemoryRepository — pure, fast, no AWS.

One caveat baked into the workflow: --experimental-strip-types strips types, it doesn't check them. A type-broken test can pass at runtime. Type checking is its own step: npm run typecheck (tsc --noEmit). Run both.

Deployment

scripts/deploy-frontend.sh (npm run deploy) encodes a caching lesson learned the hard way:

1. Build with the production env baked in.
2. Sync dist/ to S3 with --cache-control "public,max-age=31536000,immutable" — excluding index.html. Hashed assets can cache forever.
3. Upload index.html separately with --cache-control "no-cache" — it's the pointer to the current hashed bundle, and caching it once left users stuck on a stale app until a hard refresh.
4. Invalidate CloudFront.

The backend deploys with npx cdk deploy from backend/; the same handlers that ran against the memory store in dev now run on Lambda against DynamoDB, with the caller identity coming from Cognito instead of a dev header.

The YouTube Music corner

The provider seam was proven before the backend even existed. poc/ytmusic_search.mjs is a standalone spike showing that the unofficial ytmusic-api library can search YouTube Music with no authentication at all, and vite-plugin-ytmusic.ts runs that library inside the Vite dev server, serving /youtube-music/search and /youtube-music/tracks/:id at the same paths a production proxy would — so the YouTubeMusicProvider works end-to-end in npm run dev with zero configuration.

What's deliberately not there yet: playlist creation (ytmusic-api is read-only; the dev proxy returns 501), the production backend routes, and the create-league picker entry. The full story of what exists, why it's gated, and what it takes to finish is the subject of its own post: Adding a New Music Provider: YouTube Music.

Closing thought

The codebase is small enough to read in an afternoon, but the seams make it behave like a much bigger system: every feature was developed against mocks, tested against the memory store, and deployed unchanged against AWS. If you take one thing from this tour, take the pattern — a port, two implementations, and an environment variable is most of what "works offline, deploys serverless" actually requires.
